Heavy-Duty Steel Street Light Poles (4m–12m) – Hot-Dip Galvanized & Corrosion-Resistant for Municipal Solar Lighting Projects.

1. Q235/Q355 Premium Steel: High-tensile carbon steel construction ensures maximum structural stability for heavy solar wind loads.
2. 20-Year Anti-Rust Warranty: Industrial hot-dip galvanizing inside and out, meeting international ISO 1461 standards.
3. Wind Resistance up to 45m/s: Engineered to withstand extreme weather conditions, including hurricanes and coastal salt spray.
4. Pre-Drilled for Easy Integration: Customized arm brackets and cable entries precisely matched to your specific solar street light models.
5. Versatile Design Options: Available in Conical, Octagonal, or Cylindrical shapes with various arm configurations (Single, Double, or Custom).

Inquire

Download

Description
Specification
Advantages
Faq

Description

1. Unrivaled Protection.
Our poles undergo a rigorous hot-dip galvanizing process followed by an electrostatic powder coating. This dual-layer defense provides a beautiful aesthetic finish while ensuring the pole remains maintenance-free for decades in humid or saline environments.
Rock-Solid Foundation.
The reinforced base plate and gussets are designed based on precise wind-load calculations for your project's specific height and fixture weight, ensuring zero risk of bending or collapse.
Maximize Your ROI.
We offer specialized "nesting" or knock-down packaging that allows more poles to fit per container, significantly reducing your international freight costs per unit.

Specification

Height	4M	5M	6M	7M	8M	9M	10M	11M	12M
Top diameter	60mm	60mm	60mm	70mm	70mm	75mm	75mm	75mm	90mm
Bottom diameter	140mm	140mm	140mm	155mm	155mm	175mm	190mm	190mm	195mm
Thickness	2-3.5mm	2-3.5mm	2-3.5mm	3-3.5mm	3-3.5mm	3-4mm	3-4mm	4-5mm	4-5mm
Base plate	12260260mm	12260260mm	12260260mm	14280280mm	14280280mm	16350350mm	16350350mm	18400400mm	18400400mm
Hot dip galvnaized	≥80um	≥80um	≥80um	≥80um	≥80um	≥80um	≥80um	≥80um	≥80um
Powder coating	≥80um	≥85um	≥85um	≥85um	≥85um	≥85um	≥85um	≥85um	≥85um
All of pole could be customized

Product Advantages

Full Infrastructure Compatibility

Perfect for municipal roads, highways, industrial parks, and parking lots.
Rapid Site Deployment

Pre-wired and pre-drilled designs reduce on-site labor costs and installation errors.
Customizable Aesthetics

Choose from various RAL colors to match urban branding or architectural themes.
One-Stop Procurement Service

Minimize coordination effort by sourcing poles, lights, and brackets from a single, accountable manufacturer.

Faq

What wind speed are your 12-meter poles designed to withstand?
+

Our standard 12m poles are engineered for 160 km/h winds (45 m/s). For hurricane-prone areas, we can increase the wall thickness and base reinforcement to meet specific safety codes.
How do you prevent internal rusting inside the pole?
+

We use a full-immersion hot-dip galvanizing process, meaning the molten zinc coats both the interior and exterior surfaces, providing complete protection that paint-only poles lack.
Can you provide customized brackets for my existing solar lights?
+

Yes. We offer OEM bracket design. Simply provide the diameter of your light's mounting hole, and we will customize the arm size for a seamless fit.
What is the standard wall thickness for different pole heights?
+

Typically, we use 3.0 mm for 4-6m poles and 4.0 mm to 5.0 mm for 8-12m poles, but this can be adjusted based on the total weight of the solar panels and battery box.
